  All Products >> Load-Free Dynamometry Tester (details)
   Description

Load-Free Dynamometry Tester







Scope

DC permanent-magnet brushed motor (without reducer) load-free dynamometry, and also electric strength, current ripple analysis, vibration, noise, label print & check, data upload to server, and all other FAT and management items; Motors of special specifications can be tested upon order request.



Basic Functions

1. Perform no-load motor test to obtain the electromechanical properties of a motor, just power the motor to perform no-load test; it eliminates the operation of brakes, torque sensors, couplings and countershafts, and makes the test convenient and fast

2. Display of torque, speed, input power, output power, voltage, current, efficiency and other dynamometry curves, or display of data at POLs (points of load), stall points and other designated points

3. Using motor terminal voltage feedback in internal precision programmable switching power supply, fully offset the test circuit voltage drop and keep the voltage actually applied on a motor accurate. Test voltage settable;

4. The motor model project test criteria can be established;

5. Set limits for test items, issue sound or light alarm in case of test data over-limit, give NG or GO result in a screen

6. Save test data, and export them via a USB interface.



Optional



CW and CCW Test

Direction Auto-Identification

HIPOT, Insulation Resistance Test

Motor Internal Parameter Test

Current Waveform Detection & Analysis

Total Vibration Acceleration Test

Total Noise dB(A) Test (with no noise isolation room required)

Abnormal Sound Auto-Identification

Hall Test

Error Prevention and Correction

Label Print and Check

System Integration



Technical Specifications



Item

P933

P938

Motor Parameter

Rated Voltage (V)

630

100250

No-Load Current (A)

0.052

0.021

No-Load Speed (RPM)

50025000

Stall Torque (N.m)

0.110

Built-In Power Supply

Output Power (W)

600

Output Voltage (V)

130

50250

Output Current (A)

≤30

≤5

Characteristics

Voltage settable, motor port voltage sampling & regulation, take the maximum output current to make the current constant in case of current over-limit

Voltage Test Accuracy

±0.2%

Current Test Accuracy

±0.5%

Speed Test Accuracy

±0.1% (@ 12 bars, 5000 RPM

Torque Test

Adaptive

Electromechanical Characteristic Curve

U, I, Pi, T, n, Po, η

Input Device

Keyboard & mouse

Display

14’′ LCD

Host Computer

CPU clock frequency 1.8G HDD 64 G

Power Supply

Voltage 220V 50Hz

Operating Environment

Temperature 040, Humidity 85%

Outline Dimensions

Desktop: 520×280×420, all-in-one: 600×6001000×1750

Weight

Desktop machine: 20kg integrated cabinet machine: about 100kg

Remarks

For technical indicators, test functions, system functions, shape & structure, configuration of fixtures & clamps, the ordering requirements shall prevail



Test Screen Example
